Key Features

5 port 10/100/1000Mbps switch (10BASE-T/100BASETX/1000BASE-T)
3.3 to 5 VDC Input Reverse Polarity Protected
Transient Voltage Protected
1500V magnetic isolation between ports
Auto MDI/MDIX
Power and link indicators for all ports visible from all angles
Board-to-board and wire-to-board compatible
IDC style connectors (Compatible with board-to-board and wire-to-board connections)
IEEE 802.3x flow control
Non-blocking layer 2 operation

Manuals & Resources

BRAINBOXES LTD Switches & Bridges

Mfr # PE-515 SKU 14529085 UPC 837324005325

$59.88 MSRP $81.68 Save 27%

Regular price saves you $21.80 against MSRP.

Available

PURE COMPATIBILITY, PURE STABILITY, PURE DESIGN. THE PERFECT FIT FOR ANY STABLE,

PURE EMBEDDED 5 PORT GBE SWITCH SFF WITH BOARD TO BOARD CABLE CONN
Brainboxes Pure Embedded 1G 5 Port Industrial Ethernet Switch - 5 Ports - Gigabit Ethernet - 10/100/1000Base-T - 2 Layer Supported - Twisted Pair - Compact
Brainboxes Pure Embedded 1G 5 Port Industrial Ethernet Switch
5 Ports - Gigabit Ethernet - 10/100/1000Base-T - 2 Layer Supported - Twisted Pair - Compact

Product Type	Ethernet Switch
Input Voltage	3.3 V DC
Input Voltage	5 V DC
Manufacturer Part Number	PE-515
Power Source	DC
Layer Supported	2
Weight (Approximate)	0.88 oz
Form Factor	Compact
Manufacturer	Brainboxes Limited
Product Name	Pure Embedded 1G 5 Port Industrial Ethernet Switch
Network Technology	10/100/1000Base-T
Brand Name	Brainboxes
Height	0.6"
Width	2.2"
Depth	2.2"
Maximum Data Transfer Rate	128 MB/s
Ethernet Technology	Gigabit Ethernet
Network (RJ-45)	Yes
Media Type Supported	Twisted Pair
Total Number of Network Ports	5
Port/Expansion Slot Details	5 x 10/100/1000BASE-T Gigabit Ethernet RJ-45 Network Port
Networking Standards	IEEE 802.3x
Networking Standards	IEEE 802.3ab

Overview

The perfect fit for any stable, future-proof system, even where space is limited.

Stability of design guaranteed compatibility until at least 2035 (min. 10 years)
Compact form - smaller than a standard business card (55x55mm)
Seamless integration with design software - logical placements and fixed distances
3D CAD files
Board-to-board and board-to-cable connection
LEDs visible in all orientations - option to route through fibre
