Key Features

1 Port RS-232 with Power over Ethernet IEEE802.3af
Ethernet to Serial Device Server
Data rate from 110 to 1,000,000 baud (1 MegaBaud)
Install Virtual Com ports or use the Software APIs for Visual Basic, C# and more
Serial Port Tunnelling allows serial cable replacement over any distance, no software required
Optional DIN rail mounting kit and stand alone power supply

Manuals & Resources

MANUAL User Manual › DATASHEET Product Datasheet › BROCHURE Manufacturer Brochure › MANUAL Assembly Instructions › WARRANTY Warranty Information › DATASHEET Product Fiche › GUIDE Energy Guide › SAFETY Safety Data Sheet › SAFETY Safety Data Sheet (FR) › SAFETY COSHH Sheet › TOUR Product Tour › 360 360° Product View ›

BRAINBOXES LTD Serial/Parallel Adapters

POWER OVER ETHERNET 1 RS232 POE

Mfr # ES-446 SKU 4580878 UPC 837324003710

$137.69 MSRP $187.86 Save 27%

Regular price saves you $50.17 against MSRP.

Available

Product Overview

POWER OVER ETHERNET 1 RS232 POE

POWER OVER ENET 1 RS232 POE IEEE 802.3AT & 3AF POE COMPATIBLE
Brainboxes 1 Port RS232 PoE Ethernet to Serial Adapter - DIN Rail Mountable - PC - 1 x Number of Serial Ports External - TAA Compliant
Brainboxes 1 Port RS232 PoE Ethernet to Serial Adapter
DIN Rail Mountable - PC - 1 x Number of Serial Ports External - TAA Compliant

Technical Specifications

Product Type	Serial Adapter
Manufacturer Part Number	ES-446
Platform Supported	PC
Limited Warranty	Lifetime
Weight (Approximate)	4.27 oz
Form Factor	DIN Rail Mountable
Manufacturer	Brainboxes Limited
Product Model	ES-446
Product Name	1 Port RS232 PoE Ethernet to Serial Adapter
Brand Name	Brainboxes
Country of Origin	United Kingdom
Height	1.1"
Width	3.9"
Depth	4"
Environmentally Friendly	Yes
Number of Serial Ports (External)	1
TAA Compliant	Yes

Marketing Information

1 Port RS232 PoE Ethernet to Serial Adapter
Quick Start Guide
Installation CD Including Manual
Microsoft Signed Drivers & Utilities

Ethernet to Serial device server with Power over Ethernet providing access to one RS232 serial port. Data transfer rates up to 1,000,000 baud (1 MegaBaud), coupled with 1Mbit/s line drivers deliver uncompromising performance. Baud rates can be standard values such as 9,600, 115,200, 230,000, 921,600 or user definable non standard values. Power over Ethernet (PoE) uses IEEE 802.3af standard, compatible with any PoE switch.

Our ES range provides simple instant networked serial ports. A web interface allows secure configuration and control of the serial ports over a local network or the internet using any browser.

For Windows our in-house designed (32 bit and 64 bit) driver gives you local COM ports, retaining existing software applications and allowing you to connect across your network to remote devices just as if they were attached locally.

Serial Port Tunnelling (individually configurable) allows serial cable replacement over any distance, no software required. You can access the device via TCP/IP sockets from any networked device like an Android tablet, PC or phone. On Windows OS TCP/IP sockets are handled by the Winsock API, this will differ on other OSs.
