Key Features

1 Port RS-422/485 with Power over Ethernet IEEE802.3af
Ethernet to Serial Device Server
Data rate from 110 to 1,000,000 baud
User friendly interface, simple to use, powerful in operation
Serial Port Tunnelling allows serial cable replacement over any distance, no software required
Optional DIN rail mounting kit and stand alone power supply

Manuals & Resources

MANUAL User Manual › DATASHEET Product Datasheet › BROCHURE Manufacturer Brochure › MANUAL Assembly Instructions › WARRANTY Warranty Information › DATASHEET Product Fiche › GUIDE Energy Guide › SAFETY Safety Data Sheet › SAFETY Safety Data Sheet (FR) › SAFETY COSHH Sheet › TOUR Product Tour › 360 360° Product View ›

BRAINBOXES LTD Serial/Parallel Adapters

POWER OVER ETHERNET 1 RS422/485

Mfr # ES-420 SKU 4580874 UPC 837324003734

$148.47 MSRP $202.55 Save 27%

Regular price saves you $54.08 against MSRP.

Available

Product Overview

POWER OVER ETHERNET 1 RS422/485

POWER OVER ETHERNET 1RS422/485 IEEE802.3AT & 3AF POECOMPATIBLE
Brainboxes 1 Port RS422/485 PoE Ethernet to Serial Adapter - DIN Rail Mountable - PC - 1 x Number of Serial Ports External - TAA Compliant
Brainboxes 1 Port RS422/485 PoE Ethernet to Serial Adapter
DIN Rail Mountable - PC - 1 x Number of Serial Ports External - TAA Compliant

Technical Specifications

Product Type	Serial Adapter
Manufacturer Part Number	ES-420
Platform Supported	PC
Limited Warranty	Lifetime
Weight (Approximate)	4.27 oz
Form Factor	DIN Rail Mountable
Manufacturer	Brainboxes Limited
Product Model	ES-420
Product Name	1 Port RS422/485 PoE Ethernet to Serial Adapter
Brand Name	Brainboxes
Country of Origin	United Kingdom
Height	1.1"
Width	3.9"
Depth	4"
Environmentally Friendly	Yes
Number of Serial Ports (External)	1
TAA Compliant	Yes

Marketing Information

1 Port RS422/485 PoE Ethernet to Serial Adapter
Quick Start Guide
Installation CD Including Manual
Microsoft Signed Drivers & Utilities

Ethernet to Serial device server with Power over Ethernet providing access to one RS422/485 serial port. Data transfer rates up to 1,000,000 baud, coupled with 1Mbit/s line drivers deliver uncompromising performance.

Power over Ethernet (PoE) uses IEEE 802.3af standard, compatible with any PoE switch.

Our ES range provides simple instant networked serial ports. RS485 - 1 twisted pair - half duplex configuration with autogating provides trouble free data transmission due to automatic control of data direction. A web interface allows secure configuration and control of the serial ports over a local network or the internet using any browser. For Windows our in-house designed (32 bit and 64 bit) driver gives you local COM ports, retaining existing software applications and allowing you to connect across your network to remote devices just as if they were attached locally. Serial Port Tunnelling (individually configurable) allows serial cable replacement over any distance, no software required. You can access the device via TCP/IP sockets from any networked device like an Android tablet, PC or phone. On Windows OS TCP/IP sockets are handled by the Winsock API, this will differ on other OSs.
