Key Features

With Serial ATA interface, experience high-speed data transfer and robust reliability for optimized system performance
Gigabit Ethernet is highly efficient for large file transfers, making it ideal for backups and heavy data workflows
Rack-mountable server barebone system offers easy installation and convenient access for streamlined maintenance
DDR3 SDRAM slot operates at high bus speeds with low power use, improving performance and reducing heat generation
Intel Xeon processor provides high performance, built-in security, and remote management for enterprise systems
Provides 6 USB ports for responsive and expanded device connections without interruptions

Manuals & Resources

MANUAL User Manual › DATASHEET Product Datasheet › BROCHURE Manufacturer Brochure › MANUAL Assembly Instructions › WARRANTY Warranty Information › DATASHEET Product Fiche › GUIDE Energy Guide › SAFETY Safety Data Sheet › SAFETY Safety Data Sheet (FR) › SAFETY COSHH Sheet › TOUR Product Tour › 360 360° Product View ›

INTEL Barebone Systems

INTEL SERVER SYSTEM R2308GL4DS9

Mfr # R2308GL4DS9 SKU 3807363 UPC 735858249447

$1,362.76

Available

Product Overview

Intel (R2308GL4DS9) Barebone Systems
Intel Server System R2308GL4DS9 Server Barebone System - 2U Rack-mountable - Socket R LGA-2011 - 2 x Processor Support - 512 GB DDR3 SDRAM DDR3-1600/PC3-12800 Maximum RAM Support - 16 Total Memory Slots - Serial ATA RAID Supported Controller - 8 3.5" Bay(s) - Network (RJ-45) - 10 SATA Interface(s) - Processor Support (Xeon) - 1 x 460 W
Intel Server System R2308GL4DS9 Server Barebone System - 2U Rack-mountable - Socket R LGA-2011 - 2 x Processor Support
512 GB DDR3 SDRAM DDR3-1600/PC3-12800 Maximum RAM Support - 16 Total Memory Slots - Serial ATA RAID Supported Controller - 8 3.5" Bay(s) - Network (RJ-45) - 10 SATA Interface(s) - Processor Support (Xeon) - 1 x 460 W

Technical Specifications

Product Type	Server Barebone System
Manufacturer Part Number	R2308GL4DS9
Maximum Memory Supported	512 GB
Form Factor	Rack-mountable
Manufacturer	Intel Corporation
Product Model	R2308GL4DS9
Product Name	Server System R2308GL4DS9
Processor Supported	Xeon
Product Line	Server System
RAID Levels	0, 1, 1+0
Controller Type	Serial ATA
Processor Socket	Socket R LGA-2011
Rack Height	2U
Brand Name	Intel
Memory Technology	DDR3 SDRAM
Memory Standard	DDR3-1600/PC3-12800
Height	3.4"
Width	16.9"
Depth	28"
64-bit Processing	Yes
Number of SATA Interfaces	10
Number of Power Supplies Installed	1
Graphics Memory Technology	DDR3 SDRAM
Graphics Memory Accessibility	Shared
Number of Processors Supported	2
RAID Supported	Yes
Ethernet Technology	Gigabit Ethernet
Number of 3.5" Bays	8
Number of PCI Express x8 Slots	6
Network (RJ-45)	Yes
Maximum Power Supply Wattage	460 W
Total Number of USB Ports	6
Total Number of Expansion Slots	6
Total Number of Memory Slots	16

Marketing Information

Incredible Server Performance and Flexibility in an Energy Efficient Custom Design

The Intel® Server System R2300GL family takes full advantage of the new Intel® Xeon® processor E5-2600 product family capabilities with the Intel® Server Board S2600GL family. The Intel Server System R2300GL family features an energy efficient spread core design and maximum (512 GB) memory capacity with up to 16 DIMMS, S2600GL-based rack-optimized server systems deliver unmatched performance, I/O capacity, and flexibility in an expansive family of 1U and 2U systems for the most demanding enterprise data center, cloud, or high performance computing (HPC) environments.
