CONNECT YOUR SATA HARD DRIVE OR BLU-RAY/DVD/CD-ROM DRIVE TO AN IDE MOTHERBOARD -

Product image

Key Features

Connect a SATA device to an IDE/ATA motherboard or controller card
Complete hardware solution; no software required
Support for 48-bit Logical Block Addressing (LBA)
Compliant with SATA revision 1.0 specification
Supports SATA I/II/III (1.5/3/6Gbps) drives
Compatible with Ultra ATA 133 specification
Supports 2.5" , 3.5" , and 5.25" SATA Drives
ODD (Optical Disk Drive) support, including Blu-ray, DVD, and CD-ROM drives

Manuals & Resources

MANUAL User Manual › DATASHEET Product Datasheet › BROCHURE Manufacturer Brochure › MANUAL Assembly Instructions › WARRANTY Warranty Information › DATASHEET Product Fiche › GUIDE Energy Guide › SAFETY Safety Data Sheet › SAFETY Safety Data Sheet (FR) › SAFETY COSHH Sheet › TOUR Product Tour › 360 360° Product View ›

STARTECH.COM Hard Drive Adapters

CONNECT YOUR SATA HARD DRIVE OR BLU-RAY/DVD/CD-ROM DRIVE TO AN IDE MOTHERBOARD -

Mfr # IDE2SAT2 SKU 3639227 UPC 065030852258

$15.35 MSRP $22.54 Save 32%

Regular price saves you $7.19 against MSRP.

Available

Product Overview

CONNECT YOUR SATA HARD DRIVE OR BLU-RAY/DVD/CD-ROM DRIVE TO AN IDE MOTHERBOARD -

StarTech.com 40-Pin IDE PATA to SATA Adapter Converter for HDD/SSD/ODD
StarTech 40-Pin IDE PATA to SATA Adapter Converter for HDD/SSD/ODD, TAA - Connect your SATA Hard Drive or Blu-ray/DVD/CD-ROM Drive to an IDE motherboard - IDE to SATA Adapter - IDE to SATA Converter - ATA to SATA Adapter - PATA to SATA Converter - PATA to SATA Adapter - IDE to SATA adapter with SSD/HDD/ODD Support
StarTech 40-Pin IDE PATA to SATA Adapter Converter for HDD/SSD/ODD, TAA
Connect your SATA Hard Drive or Blu-ray/DVD/CD-ROM Drive to an IDE motherboard - IDE to SATA Adapter - IDE to SATA Converter - ATA to SATA Adapter - PATA to SATA Converter - PATA to SATA Adapter - IDE to SATA adapter with SSD/HDD/ODD Support

Technical Specifications

Product Type	IDE to SATA Adapter
Manufacturer Part Number	IDE2SAT2
Packaged Quantity	1 Each
Limited Warranty	2 Year
Weight (Approximate)	1 oz
Length	3"
Manufacturer	StarTech.com
Product Name	40-Pin IDE PATA to SATA Adapter Converter for HDD/SSD/ODD
Brand Name	StarTech.com
Country of Origin	Taiwan
Height	0.9"
Width	0.8"
Environmentally Friendly	Yes
Environmental Certification	EU RoHS
Product Color	Black
Color Family	Black
Product Material	Plastic
Product Material	Steel
Environmental Compliance	Restriction of Hazardous Substances (RoHS) 2
Environmental Compliance	Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
Environmental Compliance	Waste Electrical and Electronic Equipment Directive (WEEE)

Marketing Information

40-Pin IDE PATA to SATA Adapter Converter for HDD/SSD/ODD
1 x LP4 Molex to SP4 Power Cable
1 x Instruction Manual

The IDE2SAT240-pin IDE toSATA adapter enables you to connect a SATA I/II/III drive to an availableIDE/ATA 33/66/100/133 motherboard port -a cost effective solution that allows you to add newer SATA drives, andkeepyourexisting motherboard. The IDE/SATA adapter offers a cost-effective solution for bridging the gap between a newer 2.5"/3.5"/5.25" SATA drive and older IDE motherboard port. The IDE2SAT2 also features ODD (Optical Disk Drive) support, allowing you to a add Blu-ray, DVD, orCD-ROM drives to an older IDE motherboard. TheIDE/SATA adapter is backed by a StarTech.com 2-year Warranty and free lifetime technical support. More from the Manufacturer
