ASUS PROART B850-CREATOR WIFI NEO EMPOWERS CREATORS. IT BOASTS PCIE 5.0 X16 AND

• Processor (Socket): AMD Socket AM5.
• Processor (Series): AMD Ryzen™ 9000/8000/7000 Series and AMD EPYC™ 4005 Series processors.
• Memory: 4 x DIMM slots, max. 256GB, DDR5 memory. Supports high-speed DDR5, including overclocked modules (up to 9000+ MT/s).
• Expansion Slots: 2 x PCIe® 5.0 x16 slots (supports x16 or x8/x8 modes) and 1 x PCIe 4.0 x16 slot (max. x4).Storage: 3 x M.2 slots (2 x PCIe 5.0 x4, 1 x PCIe 4.0 x4) and 4 x SATA 6Gb/s ports.
• Power Requirement: 24-pin main power and 8+8 pin 12V connectors.

ProArt logoB850-Creator WiFi Neo

The ProArt B850-Creator WiFi Neo is designed to empower creators at every level, delivering optimized performance for the latest AMD Ryzen™ 9000, 8000, and 7000 Series processors, as well as AMD EPYC™ 4005 Series CPUs. Featuring a robust 14+2+1 power stage design, DDR5 support, PCIe® 5.0 expansion, and ultrafast connectivity-including dual 5G Ethernet and WiFi 7-it provides a reliable foundation for demanding creative workloads.

With a refined aesthetic that reflects a professional and elegant design philosophy, the motherboard showcases layered black tones accented with metallic gold details. This platform seamlessly combines performance, connectivity, and design, delivering the power required for today's advanced AI PC applications.

All You Need for Maximum Productivity | Ultrafast Networking | Two 5G Ethernet ports

Two 5G Ethernet connectivity provides flexible network configuration for professional environments, enabling creators to allocate dedicated bandwidth for online connectivity and local storage systems to enhance workflow efficiency, data integrity, and system reliability.

WiFi 7

The revolutionary WiFi 7 is faster than standard WiFi 6, thanks to tech like 160 MHz channels on the 6GHz band and 4K QAM. Multi-Link Operation (MLO) provides a more stable WiFi connection and lower latency, unlocking the realms of the unknown in gaming, streaming and industrial IoT.

MLO Wizard

MLO Wizard assesses your environment for Multi-Link Operation support across your device, router and operating system, while also visualizing the current traffic capacity on each of your router's frequency bands.

The Core of Your Powerful Workstation | Robust Power Design

Designed to meet the needs of high-core-count CPUs, the ProArt B850-Creator WiFi Neo features 14(80A)+2(80A)+1(80A) power stages that integrate high-side and low-side MOSFETs and drivers into packages rated for 80 amps each. This configuration ensures optimal power delivery, efficiency, stability and performance for both current and future AMD processors.

Eight-Layer Server-Grade Design

Built on an eight-layer server-grade stack for precise signals and stable performance.

ProCool Connectors

These are built to tight specifications to ensure flush contact with PSU power lines. The resulting lower impedance helps to prevent hotspots and connector failure.

Superior Chokes & Capacitors

These are engineered to resist extreme temperatures, providing a higher level of performance than the industry standard.

Digi+ VRM Control

The ASUS Digi+ voltage-regulator module (VRM) is one of the finest in the industry and ensures ultra-smooth power delivery to the CPU.

Intelligent AI Solutions | AI Cache Boost

Supercharge your large language model (LLM) workflows with AI Cache Boost. Exclusive to ASUS AMD 800 and 600 series motherboards that use Ryzen™ 9000 Series CPUs, this BIOS setting optimizes CPU cache and memory pathways to deliver up to 29% faster local LLM performance with high-speed memory tuning.

ASUS AI Advisor

Using AI technology to understand natural-language questions or scenario descriptions, ASUS AI Advisor allows users to explore the functionality and advanced features of ASUS motherboards in a simple and straightforward way.
