Key Features
- Expand your network capacity and fulfill requirement with this 2 transceiver/media converter
- Meet the multiple network connectivity needs of today's network environment with this 2 transceiver/media converter
- With 10Base-T technology get up to 10Mbps data transfer rate over twisted pair cable
- The DIN Rail Mountable provides convenient installation
- Supports twisted pair cables for durability and improved signal transfer while ensuring smooth and seamless data transfer
PERFECT FOR CITY SURVEILLANCE, AIRPORTS AND OTHER LONG DISTANCE INSTALLATIONS, A
03534-001
SKU 15422489
UPC 7331021095403
Regular price saves you $42.99 against MSRP.
Contact us to check availability
Product Overview
PERFECT FOR CITY SURVEILLANCE, AIRPORTS AND OTHER LONG DISTANCE INSTALLATIONS, A
- AXIS (03534001) Transceivers/Media Converters
- AXIS TU8008 Media Converter - Network (RJ-45) - 2x PoE (RJ-45) Ports - 2.5 Gigabit Ethernet, Ethernet, Fast Ethernet, Gigabit Ethernet - 10Base-T, 100Base-T, 1000Base-T, 2.5GBase-X, 100Base-X, 1000Base-X - 2 x Expansion Slots - SFP - 2 x SFP Slots - Power Supply - DIN Rail Mountable, Wall Mountable - TAA Compliant
- AXIS TU8008 Media Converter
- Network (RJ-45) - 2x PoE (RJ-45) Ports - 2.5 Gigabit Ethernet, Ethernet, Fast Ethernet, Gigabit Ethernet - 10Base-T, 100Base-T, 1000Base-T, 2.5GBase-X, 100Base-X, 1000Base-X - 2 x Expansion Slots - SFP - 2 x SFP Slots - Power Supply - DIN Rail Mountable, Wall Mountable - TAA Compliant
Technical Specifications
| Product Type | Transceiver/Media Converter |
| Manufacturer Part Number | 03534-001 |
| Power Source | Power Supply |
| Weight (Approximate) | 14.78 oz |
| Form Factor | DIN Rail Mountable |
| Form Factor | Wall Mountable |
| Manufacturer | Axis Communications |
| Product Model | TU8008 |
| Product Name | TU8008 Media Converter |
| Network Technology | 10Base-T |
| Network Technology | 100Base-T |
| Network Technology | 1000Base-T |
| Network Technology | 2.5GBase-X |
| Network Technology | 100Base-X |
| Network Technology | 1000Base-X |
| Brand Name | AXIS |
| Plug/Connector Type | Terminal Block (6 Wire) |
| Expansion Slot Type | SFP |
| Height | 7" |
| Depth | 3.4" |
| Ethernet Technology | 2.5 Gigabit Ethernet |
| Ethernet Technology | Ethernet |
| Ethernet Technology | Fast Ethernet |
| Ethernet Technology | Gigabit Ethernet |
| Network (RJ-45) | Yes |
| Number of SFP Slots | 2 |
| Number of PoE (RJ-45) Ports | 2 |
| Media Type Supported | Twisted Pair |
| Media Type Supported | Optical Fiber |
| Total Number of Ports | 2 |
| Total Number of Expansion Slots | 2 |
| TAA Compliant | Yes |
Marketing Information
Seamlessly convert Ethernet to fiber for long-distance surveillance. Supports daisy-chain connection, operates in -40°C to +75°C (-40°F to +167°F), and mounts on walls or DIN rails. Ideal for airports, city surveillance, and more.
Easy conversion and installation
An Axis device connects to AXIS TU8008 via RJ45, and the two SFP slots allow installers to connect cameras to the network cost-effectively over long distances. The network ports can also be used for connections to additional cameras or temporarily to a laptop for local system service. Note that the Axis device requires an external power supply. AXIS TU8008 can be mounted either on a wall or on a DIN rail for flexible installation and operates reliably across a wide temperature range of -40°C to +75°C (-40°F to +167°F).
From Ethernet to optical fiber
The media converter can be connected to a daisy chain network. The maximum number of cameras that can be connected in the daisy chain depends on the generated bit rate per camera. The limitations are the link between the camera and media converter, and the link between the media converters.
For long-distance connections
Fiber optic connections are typically used in city surveillance, airports and other long-distance installations, where lightning strikes are a threat or great connection distances are required. Surveillance integrators in the field can also connect installation monitors and laptops to AXIS TU8008 for camera maintenance and control.
Shipping & Dimensions
Similar Products
HIGH-PERFORMANCE 2 MP DOME CAMERA WITH AI ANALYTICS. EXCELLENT IMAGE QUALITY THA
03501-001
AXIS TU8006 IS A SINGLE PORT 60 W MIDSPAN, COMPLIANT WITH IEEE 802.3BT AND HIGH
03223-001
AXIS TQ9602 CONDUIT TOP BOX - WHITE
