ENDEAVOR 5-10KVA SERIES: HIGH-END, TRUE SINE WAVE, ONLINE UPS, RACK/TOWER, 10000

Product image

Key Features

True double-conversion online tech
DSP design
High power factor (0.9pf)
120/208V output models
Multi-function, color LCD touchscreen
Automatic internal bypass
Independent Battery Bypass (IBB)
Smart fan control
Cold start function
USB and RS-232 communication options
REPO Port
3-year standard product warranty
Optional 5-year warranty options available
Platinum Protection Plan®
RoHS2 and Energy Star 2.0 compliant

Manuals & Resources

MANUAL User Manual › DATASHEET Product Datasheet › BROCHURE Manufacturer Brochure › MANUAL Assembly Instructions › WARRANTY Warranty Information › DATASHEET Product Fiche › GUIDE Energy Guide › SAFETY Safety Data Sheet › SAFETY Safety Data Sheet (FR) › SAFETY COSHH Sheet › TOUR Product Tour › 360 360° Product View ›

MINUTEMAN UPS Industrial UPS

ENDEAVOR 5-10KVA SERIES: HIGH-END, TRUE SINE WAVE, ONLINE UPS, RACK/TOWER, 10000

Mfr # ED10KRT-6KTF2 SKU 15212585 UPC 784755157836

$7,414.35 MSRP $14,255.00 Save 48%

Regular price saves you $6,840.65 against MSRP.

Available

Product Overview

ENDEAVOR 5-10KVA SERIES: HIGH-END, TRUE SINE WAVE, ONLINE UPS, RACK/TOWER, 10000

Minuteman Endeavor ED10KRT-6KTF2 10000VA Rack/Tower UPS - 5U Rack/Tower - 2 Minute Stand-by - 120 V AC, 230 V AC Input - 208 V AC, 220 V AC, 230 V AC, 240 V AC, 120 V AC, 115 V AC, 110 V AC Output - Pure Sine Wave - Serial Port - USB - LCD Display
Minuteman Endeavor ED10KRT-6KTF2 10000VA Rack/Tower UPS
5U Rack/Tower - 2 Minute Stand-by - 120 V AC, 230 V AC Input - 208 V AC, 220 V AC, 230 V AC, 240 V AC, 120 V AC, 115 V AC, 110 V AC Output - Pure Sine Wave - Serial Port - USB - LCD Display
<iframe id="gfk-spex-about-brand" scrolling="no" src="//content.etilize.com/about-brand/en_us/327.html" style="width: 100%; border: none; overflow: hidden;"></iframe><script type="text/javascript" src="//content.etilize.com/apps/spexaccess/resources/js/iframeResizer.js"></script>

Technical Specifications

Application/Usage	IT
Application/Usage	Telecommunication
Application/Usage	Security
Application/Usage	Business
Application/Usage	Infrastructure
Application/Usage	Server
Application/Usage	Network
Application/Usage	Industrial
Application/Usage	Large Enterprise
Application/Usage	Corporate
Application/Usage	VoIP
Product Type	Double Conversion Online UPS
Display	LCD
Efficiency	93%
Input Voltage	120 V AC
Input Voltage	230 V AC
Manufacturer Part Number	ED10KRT-6KTF2
Limited Warranty	3 Year
Output Voltage	208 V AC
Output Voltage	220 V AC
Output Voltage	230 V AC
Output Voltage	240 V AC
Output Voltage	120 V AC
Output Voltage	115 V AC
Output Voltage	110 V AC
Weight (Approximate)	347.13 lb
Form Factor	Rack/Tower
Manufacturer	Para Systems, Inc
Product Model	ED10KRT-6KTF2
Product Name	Endeavor ED10KRT-6KTF2 10000VA Rack/Tower UPS
Network Management	RS-232
Product Line	Endeavor
Protection Type	Surge
Surge Energy Rating	3140 J
Waveform Type	Pure Sine Wave
Rack Height	5U
Brand Name	Minuteman
Plug/Connector Type	Hardwired
Input Voltage Range	180 V AC - 280 V AC
Output Frequency	50 Hz
Output Frequency	60 Hz
Height	15.4"
Width	17.2"
Input Frequency	40 Hz
Input Frequency	70 Hz
Phase	Single Phase
USB	Yes
Maximum Operating Temperature	104°F (40°C)
Serial Port	Yes
Backup/Run Time (Half Load)	7 Minute
Backup/Run Time (Full Load)	2 Minute
Battery Characteristics	Hot-swappable
Load Capacity (VA)	10000 VA
Load Capacity (Watt)	8730 W
Replaceable Battery	Yes
Energy Star	Yes
EPO Port	Yes
Maximum Operating Elevation	15000 ft
Maximum Storage Elevation	50000 ft
Operating Humidity	0% - 95%
Storage Relative Humidity	0% - 95%
Storage Temperature	5°F (-15°C) - 131°F (55°C)
Energy Efficiency Certification	ENERGY STAR 2.0
Environmental Compliance	Restriction of Hazardous Substances (RoHS) 2

Marketing Information

3 Years (Electronics and Batteries)

Endeavor ED10KRT-6KTF2 10000VA Rack/Tower UPS
Comm. Cables

Endeavor 5-10kVA Series | Double Conversion Rack/Tower UPS

The Endeavor 5-10kVA Series delivers uninterrupted power for vital IT, telecom, and security setups. With a clear LCD Display for instant updates on AC, battery, and UPS status, this UPS is generator-compatible, versatile, and ensures maximum uptime. Offering pure sine wave output and adaptability for critical applications, it's the ultimate choice for reliability and efficiency.

Key Features

The Endeavor 5-10kVA is a high-density, double-conversion online UPS series providing unparalleled power protection for critical IT and business infrastructure. With a unique multi-color touchscreen panel for easy management and monitoring, this UPS offers a wide range of installation options and is ideal for servers, networks, industrial applications. The Endeavor 5-10kVA has advanced features like predictive battery replacement and hot-swappable batteries, it's designed for IT professionals and administrators needing reliable power solutions.

New Advanced Features

Multi-color, touchscreen LCD panel for easy UPS configuration and monitoring
Compact design: 4U for 5/6kVA, 5U for 8/10kVA (208VAC models)
High-frequency design for efficient performance
Space-saving solution for higher density installations
Predictive Battery Replacement feature with early warning alarms
Tool-less, front-panel battery connection and replacement
Hot-swappable batteries for continuous power
Independent battery chargers for unlimited runtime
Automatic recognition of additional battery packs for recalculating runtimes
Easy connect transformer module with NEMA input plug Wide range of 120V and 208V NEMA output receptacles available in standard configurations
Smart ECO Mode feature allows for increased energy savings
