Key Features
- For a better airflow, mid-tower structure supports up to 14 fan(s) with ample space to store hardware
- Mini ITX motherboard builds a perfect symmetry of hardware components required in media server or NAS box
- 8 bays help in upgrading the system by increasing number of hardware components
FRAME 5000D RS ARGB BLACK - CABINET TYPE: SYSTEM CABINET - FRONT PORTS: USB 3.2
CC-9011309-WW
SKU 15195525
UPC 840440491293
Regular price saves you $32.25 against MSRP.
Contact us to check availability
Product Overview
FRAME 5000D RS ARGB BLACK - CABINET TYPE: SYSTEM CABINET - FRONT PORTS: USB 3.2
- Corsair (CC9011309WW) Connector Cables
- Corsair FRAME 5000D RS ARGB High-Airflow Mid-Tower PC Case - Mid-tower - Black - Steel, Tempered Glass, Plastic - 8 x Bay - 4 x 140mm Fan(s) Installed - Mini ITX, Micro ATX, ATX, EATX Motherboard Supported - 14 x Fan(s) Supported - 2 x Internal 3.5" Bay - 6 x Internal 2.5" Bay - 8x Slot(s) - 5 x USB(s) - 1 x USB 3.2 Gen 2 Type C, 4 x USB 3.2 Gen 1 Type-A - 1 x Audio In - 1 x Audio Out - Fan/Liquid Cooler
- Corsair FRAME 5000D RS ARGB High-Airflow Mid-Tower PC Case
- Mid-tower - Black - Steel, Tempered Glass, Plastic - 8 x Bay - 4 x 140mm Fan(s) Installed - Mini ITX, Micro ATX, ATX, EATX Motherboard Supported - 14 x Fan(s) Supported - 2 x Internal 3.5" Bay - 6 x Internal 2.5" Bay - 8x Slot(s) - 5 x USB(s) - 1 x USB 3.2 Gen 2 Type C, 4 x USB 3.2 Gen 1 Type-A - 1 x Audio In - 1 x Audio Out - Fan/Liquid Cooler
Technical Specifications
| Product Type | Computer Case |
| Manufacturer Part Number | CC-9011309-WW |
| Motherboard Supported | Mini ITX |
| Motherboard Supported | Micro ATX |
| Motherboard Supported | ATX |
| Motherboard Supported | EATX |
| Limited Warranty | 2 Year |
| Weight (Approximate) | 34.13 lb |
| Features | Cable Management |
| Features | ARGB Fan |
| Features | Cable Shroud |
| Features | Dust Filter |
| Form Factor | Mid-tower |
| Manufacturer | Corsair |
| Microphone | Yes |
| Product Name | FRAME 5000D RS ARGB High-Airflow Mid-Tower PC Case |
| Product Line | FRAME |
| Brand Name | Corsair |
| Cooler Type | Fan/Liquid Cooler |
| Height | 21.3" |
| Width | 9.8" |
| Depth | 21.9" |
| Number of Fans Supported | 14 |
| Number of Fans Installed | 4 |
| Number of Internal 2.5" Bays | 6 |
| Number of Internal 3.5" Bays | 2 |
| Front USB | Yes |
| Front Audio In | Yes |
| Front Audio Out | Yes |
| Number of Total Expansion Bays | 8 |
| Total Number of USB Ports | 5 |
| Fan Size Supported | 4.72" |
| Fan Size Supported | 5.51" |
| Fan Size Supported | 7.87" |
| Installed Fan Size | 5.51" |
| Total Number of Audio In Ports | 1 |
| Total Number of Audio Out Ports | 1 |
| Headphone/Microphone Combo Port | Yes |
| Total Number of Expansion Slots | 8 |
| Product Color | Black |
| Maximum CPU Cooler Height | 6.89" |
| Color Family | Black |
| Product Material | Steel |
| Product Material | Tempered Glass |
| Product Material | Plastic |
| USB Port Details | 1 x USB 3.2 Gen 2 Type C |
| USB Port Details | 4 x USB 3.2 Gen 1 Type-A |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Maximum GPU Length | 17.72" |
| Window Panel | Yes |
| Window Panel Location | Left Side |
| Installed Fan Size Details | 4 x 140mm |
Marketing Information
BUILD WITH THE BEST
50 SERIES GPUs ARE HERE
Pair a next-gen GPU with quality CORSAIR components for top-shelf performance and no hassles, right out of the box.
BUILD YOUR WAY
ENDLESS MODULAR POSSIBILITIES
The revolutionary FRAME Modular Case System redefines customization. Want to upgrade the motherboard tray to billet aluminum? Want to replace your front I/O panel for more USB ports? Now you can.
This case evolves with your needs, offering near limitless options for upgrades and changes.
FAN FOCUSED
INFINIRAIL FAN MOUNTING SYSTEM
This steel multi-point mounting system provides unmatched flexibility for front and roof fan configurations. Easily slide the rail to mount fans up to 200mm (140mm in the roof) exactly where you need them, ensuring targeted airflow without limitations of fixed mounting points.
MORE ROOM TO CHILL
SUPPORT FOR MULTIPLE 420mm RADIATORS
Cooling options are abundant with three mounting locations for radiators up to 420mm in size, and you can install up to 12x 140mm or 14x 120mm fans, ensuring continuous cool air intake and efficient hot air exhaust.
AIR BENDING
FOUR RS140 FANS INCLUDED
RS140 ARGB PWM fans feature daisy-chainable connections for easy setup. Their magnetic dome bearings minimize friction, delivering a perfect combination of high airflow and quiet operation.
IMPROVED COOLING
UP TO 12% MORE AIRFLOW
Engineered for maximum airflow and minimal resistance, the new 3D Y-pattern steel front panel ensures a smooth, unobstructed path for cool air, enhancing overall cooling.
MAKE IT YOUR OWN
DESIGNED TO BE MODIFIED
Customize the FRAME 5000D with a variety of premium, easy-to-install accessories.
NEXT-LEVEL CABLE MANAGEMENT
RAPIDROUTE 2.0
CORSAIR has upgraded RapidRoute to version 2.0, featuring a pegboard motherboard tray with detachable and rotatable tie-down buckles and all-new cable looms to easily wrap excess cable lengths for a tidy and professional appearance.
FUTURE PROOF
GET IN THE FRAME
Ensure your build has excellent airflow with careful cable routing and support for the latest motherboards and graphics cards.
NO VISIBLE CABLES
Fully compatible with reverse-connector motherboards from Asus, MSI, and Gigabyte, allowing for unobstructed airflow and a super-clean build.
SAG-FREE GRAPHICS CARDS
Every CORSAIR FRAME 5000D includes a GPU Anti-sag Stabilization Arm to keep your GPU steady, so you never have to worry about damaging your PCIe slot.
CABLE SHROUD
Keep unused and overly long cables out of sight with the cable shroud for a clean and organized interior.
ARGB LIGHT STRIP
An RGB light strip above the front I/O adds a dash of customizable color to the front of the chassis.
WIDE COOLING FLEXIBILITY
Customize your cooling setup with room for up to 14x 120mm fans, plus versatile radiator mounting options including up to triple 420mm radiators in the roof, front, and side.
DIMENSIONS
The FRAME 5000D has a cavernous interior designed for high-powered builds and abundant cooling.
FAN CAPACITY
The FRAME 5000D has a cavernous interior designed for high-powered builds and abundant cooling.
